Welcome to the Elevator Virtual World !
"Virtual Elevators" - a perfect solution for Vertical Mobility
An ISO certified quality elevator solution provider
Products at a glance
We offer a wide range of quality elevator solution for Passenger / Stretcher / Freight Lift etc. with various kinds of specifications to control all type of lifts for machine room and machine room-less description.
​
OUR QUALITY PRODUCTS :-
(a) Traction Elevator for Passenger (Manual Door). (b) Traction Elevator for Passenger (Automatic Door).
(c) Traction Elevator for Hospital, Nursing Homes etc. (d) Traction Elevator for Industry as Freight or Goods Lift.
(e) Traction Elevator for Automobile Showroom as Car Lift. (f) Traction Elevator for Shopping Malls as Capsule (Glass) Lift.
A passenger elevator is designed to ferry people from point A to B vertically. Generally passenger elevators are available in passenger carrying capacity from 4 person to 13 persons with speed varying between 0.70 m/sec to 1.0 m/sec.
“Virtual Elevators® Private Limited” offers variety of automatic door elevator with new technologies such as :-
-
Adjustable Door Opening and Closing Time.
-
Emergency Alarm Button.
A hospital elevators are used for simple transportation of a patient on wheel chair or wheeling away a critical patients on stretcher without disturbing his life support system with doctors and nurses, smoothly and swiftly without jerks and shocks.
A Panaromic elevator is essentially installed at a place where building elevations is to be enhanced with display of moving passenger is provided with panaromic view of surroundings.
The Machine Room-Less technology eliminated the need for a machine room by attaching the hoisting machine to the guide rail, and placing all control and logic systems in an integral control space.
Freight elevators are the workhorses of the elevator world, responsible for transporting goods and materials in warehouses, industries and manufacturing environments, shopping centers, airports, train stations, and seaports.
New Technology
INTEGRATED CONTROLLER
The new-generation integrated elevator controller independently developed and based on a large number of applications and combining new features. It has the following advantages:
It can drive both AC asynchronous motor and permanent magnetic synchronous motor (PMSM), and implement switch-over between the two types of motors easily performance vector control and open-loop low speed running by modifying only one parameter.
​
Direct stop technology
Based on the distance control, the direct stop technology realizes smooth speed curve and high operating efficiency.
Full communication signal transmission
Integrate the CAN, the Modbus and other communication technologies.
​
Automatic identification grid voltage technology
Automatically correct the operation curve in accordance with the input grid voltage.
​
Multiple functions
-
Can flexibly set the elevator control functions up to 54 kinds.
-
The I/O terminal functions of the main control board, the car top board, and the main/vice manipulator command boards, can be flexibly set.
-
The high and the low levels of main control board input terminal are selectable.
Convenient car debug mode
In the car, you can connect the panel to the network communication port of car internal call board via the cable, and then you can debug the elevator and monitor its running state.
​
Two cables can make two elevators in parallel
​
Onboard small panel design
-
Design with three digital tubes and three keys.
-
Can display the fault, floors and other information, fault reset, shaft self-learning, call elevator and other operations.
-
Make easier for debugging and maintaining the elevator.
​​
All operations of product by one panel
All operations of the product can be achieved by an optional external panel, including main control board, car top board, hall call board, and door controllers.
​​
Flexible installation
The main control board can be installed on other locations.
​​
Ultra thin structure
This design is more space-saving installation.
Perfect protection for fault
-
Quick positioning method for fault based on fault sub-code.
-
60 kinds of faults sub-level treatments.
-
Immediately locking the base electrode and switching off IGBT output at fault can avoid contactor arcing, which can ensure the elevator safe and reliable operation.
-
The cosine encoder wiring mode and encoder disconnection can be identified automatically.
Three high voltage inputs of 110 - 220V AC/DC
The main control board has three programmable high voltage inputs of 110 - 220V AC/DC, which can reduce the system cost.
